3 PHASE I/P & 1 PHASE O/P
Rating: 3KVA - 30KVA

Application :
CNC Machines, Textiles & Printing Industries, Medical Equipmets, Data Centers etc.,

Features :
True on - line
Double Conversion
Buit in isolation Transformer
Pure sine Wave
Micro Processor Control
High Efficiency
PWM Technology using IGBT
Sleek Design
Longer Life
Small foot Print
Technical :
Input voltage range - 330V - 460V
Input Frequency - 50 HZ +/- 5%
Output Voltage - 230V / 220V +/- 2%
Output Frequrncy - 50 HZ +/- 1%
Battery Voltage - 120v - 360v
Crest Factor - 3 : 1
T.H.D - Less than 3% on Linear Loads
Humidity - 0% - 95% Non Condensing
Operating Temperature - 0-45 degree celsius
